Composite Chamfering Machine D900DR

Product No.：202541154356
Online Inquiry

Composite Chamfering Machine D900DR

1.Model 900 has the function of one machine with multiple functions.Straight line angle,arc chamfer and irregular curve chamfer can be completed on one machine,which can replace the NC machine center.

2.It is widely used mold manufacturing,hardware machinery,machine tool manufacturing,hydraulic parts,value manufacturing，chamfering and planing of textile machinery.

3.Chamfer processing size 0-6mm adjustable.

4.High speed cutting with indexable inserts to ensure accurate size,smoothness and high efficiency(straight line is several times that of ordinary machining methods).

5.high surface finish of machined parts.

Model	KZ-D900DR
Input Voltage	380V/50Hz
Rated Power	750W
Rated Speed	10000rmp
Chamfer Type	R Angle/C Angle(fixed 45°) Straight Slide/Curve
Chamfer Size	Linear Part: R1-R5/C0-5mm Curve Part: C0-3mm/R2、R3
Blade Model	Linear Part: SPHW120408 Curve Part: DCMT070204
Package Size	600550550mm
Equipment Weight	65kg
