MG110 band saw grinder
- Product No.:MG110
MG110 is special designed for grinding band saw blade ,it can be used for grinding the straight-tooth and the triangle tooth with no angle restrictions.
SPECIFICATIONS:
MODEL MG110
Grinding capacity Max.band saw width:90mm
Max.tooth pitch:50mm
Angle degree 15°-45°
Feed speed 0-170 teeth/min.
Motor Power 180W
Motor Speed 2800 R.P.M
Grinding Wheel Size Ø150xØ25x3(2)
Weight 78/84kg
Dimension 56x59x94cm
Standard Accessories:
Hexagon Wrench M4x1pc M5x1pc M6x1pc M8x1pc
Cross screw driver 1pc
Grinding wheel Ø150xØ25x(2)x1pc
